Buyers Products 24 Inch LED Modular Light Bars are available in four standard configurations. The amber light bar is SAE Class 1 certified and has a CA13 rating. All models feature 24 different flash patterns and a dimming mode to suit a variety of applications. Middle modules are reflective with three LEDs each. Corner modules have six LEDs each. The light bar's extruded aluminum frame is excellent at dissipating heat, and the sturdy polycarbonate lens is extremely resistant to impact. Two recessed mounting channels and a 10 ft pre-wired power/function cable make the light bar easy to install and operate. Mounting feet and controller are sold separately. Please contact Customer Service for more information. Modular light bars are backed with a 5 year warranty.
Specifications
| Amber Modules | 6 |
|---|---|
| Amp draw at 12 Volts | 6 |
| Base / Mount Type | Surface |
| Built-In Switch | No |
| Certification | CA13/SAE J845 Class 1/SAE J595 Class 1 |
| Class Level | 1 |
| Clear Modules | 0 |
| Color | Amber |
| Connector | Blunt Cut |
| Depth | - |
| Dimming Mode (y/n) | No |
| Hard Wired or Plug | Hard Wired |
| Height | 2.188 |
| Housing Material | Multiple |
| Lead Length | 10 |
| Lens Material | Polycarbonate |
| Lens Shape | Octagonal |
| Mounts Included | No |
| Number of Flash Patterns | 24 |
| Number of LEDs per Corner Strobe | 6 |
| Number of LEDs per Middle Strobe | 3 |
| Overall Width | 25 |
| Plug Included | No |
| Red Stop/Turn/Tail Modules? | No |
| Take Downs? | No |
| Traffic Adviser? | No |
| Type of Plug | Stripped Leads |
| Voltage | 12 |
| Wattage | 72 |
The Buyers Products 24 Inch Modular Light Bar, featuring six high-intensity amber LED modules, represents a pinnacle in professional-grade vehicle warning illumination. Engineered for superior visibility and unwavering reliability, this light bar is an essential component for vehicles requiring prominent visual signaling in challenging operational environments. Designed with meticulous attention to detail and adherence to stringent industry standards, this unit provides a robust, high-performance solution for a diverse array of professional applications. While nominally referred to as a "24 Inch" bar, its precise overall width measures 25 inches, a specification that underscores the product's exact dimensions and design considerations for mounting and integration.
At the core of this warning light system lies advanced LED technology, specifically optimized for maximum light output and operational longevity. Each of the six amber modules is strategically designed to contribute to a comprehensive and highly visible light pattern. The corner modules are equipped with six powerful LEDs each, engineered to project a broad and intense light beam, ensuring exceptional lateral visibility. Complementing these are the middle modules, featuring three LEDs each, enhanced by reflective optics. This combination of direct and reflected light maximizes the effective candela output and expands the visible warning zone, crucial for safety in complex traffic or work scenarios. The amber coloration is universally recognized as a warning signal, making this light bar suitable for a wide range of non-emergency and vocational applications such as construction, utility work, roadside assistance, municipal services, and security operations.
The performance of this modular light bar is underscored by its impressive electrical specifications. Operating at a standard 12 Volts, the unit maintains a current draw of 6 Amps. This balanced power consumption translates to a total wattage of 72 Watts, indicative of significant light output without imposing undue strain on the vehicle's electrical system. The efficiency of LED technology ensures that a substantial portion of this electrical energy is converted directly into light, rather than wasted as heat, contributing to the overall longevity of the system.
A cornerstone of this product's professional efficacy is its extensive array of certifications. The Buyers Products 24 Inch Modular Light Bar is certified to SAE J845 Class 1 and SAE J595 Class 1 standards. The SAE J845 specification pertains to optical warning devices for authorized emergency, maintenance, and service vehicles, while SAE J595 details tests for directional warning lamps. Both Class 1 designations signify the highest intensity level within these standards, ensuring that the light bar produces an exceptionally bright and effective warning signal, visible under virtually all ambient light conditions, including direct sunlight. This superior brightness is critical for maintaining safety distances and alerting oncoming or nearby traffic to potential hazards or operational activities.
Furthermore, the light bar carries a CA13 rating, indicating compliance with California Title 13 regulations. California Title 13 is one of the most rigorous standards for warning light systems in North America, often adopted or recognized by other jurisdictions for its comprehensive requirements concerning light output, flash rates, and environmental durability. Adherence to CA13 not only signifies compliance in California but also assures users of a product designed and tested to meet some of the most demanding performance criteria for vehicle warning lights, providing an added layer of confidence in its reliability and effectiveness. These certifications collectively guarantee that the light bar meets legal requirements for visibility and performance in a broad spectrum of professional applications, critical for operators who must adhere to strict regulatory guidelines.
Durability and structural integrity are paramount in the design of warning light equipment, particularly for units exposed to harsh external conditions. The Buyers Products light bar features an extruded aluminum frame, a material chosen for its exceptional strength-to-weight ratio and superior thermal management properties. Aluminum is an excellent conductor of heat, allowing the high-power LEDs to dissipate heat efficiently, preventing thermal degradation and extending the operational lifespan of the LED emitters. This robust frame also provides structural rigidity, protecting internal components from vibrations, impacts, and environmental stressors commonly encountered in demanding work environments.
Complementing the aluminum frame is a sturdy polycarbonate lens. Polycarbonate is renowned for its extreme resistance to impact, making it an ideal material for protective covers on warning lights. It is significantly more resilient to chips, cracks, and shattering compared to acrylic or glass, capable of withstanding debris, severe weather, and incidental contact without compromising optical clarity or structural integrity. The lens also provides UV stability, preventing yellowing or hazing over time due to prolonged exposure to sunlight, thereby maintaining optimal light transmission and visual effectiveness throughout the product's lifespan. The octagonal lens shape is not merely aesthetic but contributes to the optical efficiency, allowing for broad light dispersion from the internal LED modules.
The modular design principle, inherent to the Buyers Products light bar series, offers significant advantages in terms of performance and serviceability. While this specific model comes pre-configured with six amber modules, the modular platform suggests a design philosophy centered on interchangeable components. This approach can lead to easier maintenance and, in other configurations, the ability to customize or service individual light sections. For this particular 24-inch unit, the distribution of modules—with higher LED counts in the corners—is a deliberate design choice to enhance corner visibility, a critical safety aspect when vehicles are turning, entering, or exiting work zones. The reflective elements in the middle modules augment the light output, ensuring a consistent and powerful warning signal along the entire length of the bar.
Operational versatility is a key feature, manifest in the 24 distinct flash patterns available. This extensive range allows operators to select the most appropriate flash sequence for varying conditions, ensuring optimal conspicuity. Different flash patterns can be more effective in specific scenarios, such as high-speed traffic, adverse weather, or stationary work, enabling personnel to maximize their safety presence. While the specification table indicates "Dimming Mode (y/n): No" for an integrated dimming function, professional installation often incorporates an external controller (sold separately) that can manipulate the power delivery to achieve a dimming effect. This allows the light output to be adjusted for nighttime operations, preventing excessive glare for other motorists while still maintaining sufficient warning visibility, thus complying with specific operational requirements or personal preferences.
Installation and connectivity are streamlined for professional use. The light bar is designed for surface mounting, offering a secure and stable attachment to a variety of vehicle surfaces. Two recessed mounting channels are integrated into the frame, providing discreet yet robust points for attachment. The provision of a 10-foot pre-wired power/function cable, featuring blunt-cut stripped leads, offers significant flexibility for hard-wired installations. This ample lead length allows for optimal routing within the vehicle's electrical system, reaching control points or power sources without the need for extensive splicing or additional wiring, thus simplifying the installation process for qualified technicians. It is important to note that mounting feet and a dedicated controller are sold separately, allowing professional installers to integrate the light bar into existing vehicle systems or choose specific mounting hardware and control interfaces that best suit their application. The absence of a built-in switch or plug-and-play connector underscores its design for integration into more comprehensive vehicle electrical systems, typically managed by external, centralized controllers for optimal performance and customization.
The Buyers Products 24 Inch Modular Light Bar is a purpose-built solution for a demanding market. It does not include specialized features such as red stop/turn/tail modules, take-down lights, or traffic advisers, ensuring that its primary function remains uncompromisingly focused on high-intensity amber warning illumination. This dedicated design simplifies operation and installation for applications where these supplementary features are not required, maintaining cost-effectiveness and operational clarity.
This product is ideal for organizations and individuals who prioritize safety, compliance, and long-term performance. Its applications are widespread, ranging from heavy-duty construction vehicles operating on busy roadways to municipal service fleets maintaining infrastructure, and utility crews ensuring power and communication. Roadside assistance providers will benefit immensely from its Class 1 visibility, ensuring they are seen and safe while assisting stranded motorists. Security personnel can also deploy these light bars for clear demarcation of restricted areas or for highly visible patrolling operations.
Investment in the Buyers Products 24 Inch Modular Light Bar is further protected by a comprehensive 5-year warranty. This extended warranty period reflects the manufacturer's confidence in the product's engineering, material quality, and manufacturing processes. It provides purchasers with assurance against defects in materials and workmanship, ensuring a reliable, long-lasting warning solution that delivers exceptional value over its operational lifetime. For specific technical inquiries, integration guidance, or details regarding compatible mounting accessories and control units, customers are encouraged to contact Buyers Products Customer Service for expert assistance. This commitment to robust design, rigorous certification, and strong customer support makes the Buyers Products 24 Inch Modular Light Bar an industry-leading choice for critical warning illumination needs.
